Appendix
PLM Series Operation Manual rev 1.1.9
9.3.2 Input and Router Defaults
Autoselect: On
Input sensitivity: +26 dBu
Dante: Disabled
AES3: Terminated
Iso-Float: Enabled
Router 1: AES1 (Ch.1) as Priority 1, Analog 1 as Priority 4
Router 2: AES1 (Ch.2) as Priority 1, Analog 2 as Priority 4
9.3.3 Amplier Defaults
Attenuation: 0 dB
Polarity: Positive (In phase)
Mutes: Unmuted
Load Model: No Load Model
9.4 Current Draw and Thermal Dissipation Specications
The tables in this section provide measured current consumption and calculated heat dissipation for ve
different operating conditions for each PLM Series device.
1. Standby Mode
2. Power On (Idle - No Signal)
3. Power On (Normal Operation - Pink Noise 1/8 of Rated Power)
4. Power On (Heavy Duty Operation - Pink Noise Max Power)
5. Power On (20 kHz Sine Wave)
