Lab.gruppen PLM Series User Manual

Back Panel Interface
69
PLM Series Operation Manual rev 1.1.9
8.4.1 Primary Network Connection
The Primary Network connection is used for Lake Controller connectivity and Dante digital audio. Please
refer to section 4.2 for additional information.
8.4.2 Secondary Network Connection
The Secondary Network connection may be used for a redundant Dante digital audio network. Please refer
to section 4.2 for additional information.
8.5 Power Inlet
8.5.1 Power Connector
A Neutrik NAC3 Series powerCON connector rated at 32 A is tted to the rear of the PLM for AC mains
input. The power cable (AC cord) supplied with the PLM has the mating connector ready-tted, but may
require a mains (AC) plug specic to your country to be tted to the other end. The wiring an pinout details
are shown in Table 8-4.
powerCON
Pin
230 V
Version
115 V
Version
L
Brown Black
N
Blue White
Green/Yellow Green
Table 8-4: powerCON Connector Wiring and Pinout

Lab.gruppen PLM Series Specifications

General

DSP	Yes
Network	Ethernet
Connectors	XLR, SpeakON
Cooling	Forced air
Protection Features	Overheat, DC, short circuit
Control Software	Lake Controller
