147Expert(t) 2000

Maintenance Manual

LABRIE

ELECTRICAL SCHEMATICS

Commonly-used Symbols

Alarms

Symbol Description Part number

12V BUZZER ON

CONSOLE

ELR01005

12V BACKUP

ALARM

ON CHASSIS

ELA00700
