82 CHAPTER 3
Maintenance
The retaining bolts must be kept tight
(Figure 134. “Right side tailgate hinge
and pin”).
Figure 134. Right side tailgate hinge
and pin
The tailgate rubber seal must not show
any sign of damage. Replace the seal
as needed (Figure 135. “Tailgate
rubber seal”).
Figure 135. Tailgate rubber seal
Body/Chassis Hinges
Inspection
Monthly lubrication of the
body-to-chassis hinges should be
done. Also, inspect for cracks or
corrosion. Any crack must be reported,
and repaired by qualified personnel.
Contact the Labrie Customer Support
Center for technical support, if
required.
Tailgate Pin
Tailgate
Hinge
Retaining Bolt
