22 CHAPTER 2
Controls
Multi-cycle Control
Switch
The MULTI-CYCLE control switch allows
you to choose whether you want to
activate the packer for several
predefined cycles or for its default only
one cycle. Turning on the switch allows
packer multi-cycling when you press
the green packer start cycle button.
See “Green Start Cycle Button” on
page 21. Turning it off during the
multi-cycling operation will have the
packer finish the cycle it is on and not
starting a new one. When the switch is
turned
OFF, the packer will perform only
one cycle when you press the green
button.
Figure 19. Multi-cycle control
switch
Engine RPM Control
The Expert(t) 2000
TM
is equipped with
an engine RPM control system which
consists of the increment or decrement
of a predetermined value of the engine
RPM (revolutions per minute)
depending on the results you want to
achieve.
For example:
• if you want to achieve faster
operation of moving parts such as
the hoist and the packer, increase
the engine RPM.
• if you want to reduce the level of
noise while operating the Expert(t)
2000
TM
, decrease the engine RPM.
Increasing or decreasing the
engine RPM directly affects fuel
consumption therefore, it is an
issue to look at when using the
system.
The engine RPM controls that exist in
the Expert(t) 2000
TM
are the SPEED-UP
switch, the
SPEED-UP INHIBITOR control,
and the packer automatic speed-up.
These controls are individually
presented throughout this guide.
Note:The throttle pedal is an
element that can directly affect
the engine RPM; however, it
must not be used to control
any moving parts of the body
Multi-cycle
control switch
