83Expert(t) 2000
TM
Maintenance Manual
Figure 136. View from behind the
rear-right mud guard
Figure 137. Body-to-chassis left
hinge
Body Raised Limit
Switch
A limit switch located on the truck
chassis (Figure 138. “Body raised limit
switch”) activates the backup alarm
and a warning buzzer sounds as soon
as the body is about one foot above
the chassis. Adjust the limit switch
accordingly.
Figure 138. Body raised limit switch
This safety feature is provided to warn
people around, that the truck is
unloading and to tell the operator that
the body is still raised.
DANGER
DO NOT OPERATE THIS EQUIPMENT IF
THERE
ARE ANY SIGNS OF DAMAGE OR
INCOMPLETE
REPAIRS.
Body Hinge
Limit Switch Arm
Limit Switch
Truck
Chassis
Air Tank
