153Expert(t) 2000

Maintenance Manual

Solenoids

Symbol Description Part number

12V SOLENOID 12V SOLENOID

12V SOLENOID

VALVE

PNV01957

DUAL 12V

SOLENOID VALVE

FOR

PACKER

PNV01914
