155Expert(t) 2000

Maintenance Manual

BIPOLAR SWITCH ELB02505

NORMALLY

CLOSED

-NORMALLY

OPEN

LIMIT SWITCH

ELI00550,

ELC00200 &

ELI00850

Symbol Description Part number
