Figure 28. Main hydraulic tank
(“saddle” model)
Figure 29. Suction-line-mounted
valve
Once the engine is started, wait for the
air pressure to build up to at least
70 PSI.
Open
Ball
Valve
Open Ball
Valve
WARNING
MAKE SURE THE BALL VALVE ON THE
HYDRAULIC
TANK IS FULLY OPEN
BEFORE
STARTING THE ENGINE (SEE
FIGURE 27. “MAIN HYDRAULIC TANK
(PRESSURIZED MODEL)”, FIGURE 28.
“M
AIN HYDRAULIC TANK (“SADDLE”
MODEL)” AND FIGURE 29.
“S
UCTION-LINE-MOUNTED VALVE”).
I
F NOT OPEN, IMMEDIATE DAMAGE WILL
OCCUR
TO THE PUMP, EVEN THOUGH
THE
PTO SWITCH IS TURNED OFF.
CAUTION
DO NOT OPERATE NOR MOVE THE
VEHICLE
UNTIL THE AIR PRESSURE HAS
REACHED
70 PSI.
