Hydraulic System 95
ARM SECTION
13 g. Remove all 7 retaining bolts that hold the front cap in place.
NOTE: You may leave two retaining bolts partially unscrewed to facilitate rotation with a metallic bar.
13 h. Rotate the front cap accordingly.
Rotation can be done by turning the front cap clockwise or counter-clockwise with your
hands or by using a metallic bar.
NOTE: Make sure pump does not come apart.
1
2
3
4
To Next Page
