72 Lubrication
Taking an Oil Sample
Once you have released the residual pressure, you can take the sample.
To do so:
1. Remove the sample kit from its bag and, using a screw driver, remove the vent cap from the bottle
cap.
Figure 4-2
Vent cap
2. Remove the protective cap from the probe.
Figure 4-3
Probe cap and tip
3. Install the probe on the coupler to fill the sample bottle. Use an EMA coupler with M16×2.0
threads.
4. Fill the bottle to the level mark (the pump must be engaged to do this). Remove excess oil
through the vent. D
O NOT OPEN THE BOTTLE!
Tip
Cap
To Next Page
