Lubrication 73
Figure 4-4
Recommended oil level
5. Once the sample is taken, remove the probe from the coupler and pull out the probe to remove it
from the bottle (see Figure 4-5).
Figure 4-5
Pulling out the probe from the bottle
6. Put the seal cover over the bottle cap.
Figure 4-6
Sealing the bottle
7. Fill the identification form (sticker) and apply it on the sample bottle.
Sealed sample
