Labrie MINIMAX Maintenance Manual

Multiplexing 189
To tap into the TCM, Labrie uses the following wires on the Allison connector:
Cummins Engine Parameters
The following table contains the engine programming parameters specific to MINIMAX™ units. Enter
those parameters into Cummins engine ECUs. For more information, call LabriePlus.
NOTE: The values contained in the table above are given as an indication and may vary according to
truck specifications. If in doubt, call LabriePlus Support Service.
Table 6 Input
Wire # Description State
117 Pump pack enable Active when the brakes are used, and when the PTO and
auto-neutral switches are on (ground signal).
143 P
TO enable Active when the PTO switch is on (+12V signal).
142 Auto-neutral pack input Active when the brakes are used, and when the PTO and
auto-neutral switches are on (ground signal).
Table 7 Output
Wire # Description State
130 PTO enable output Active when the PTO switch is on and when all engine
and vehicle speed criteria are respected (+12V signal).
See Programmed Parameters on page 188.
145 Neutral signal output Active when the transmission is in neutral. This signal
(ground signal) is used to allow fast idle engagement. For
more details, refer to the electrical schematic provided
with the vehicle.
Table 8 Cummins engine parameters
Menu: Features &
Parameters
Parameter Name Value
Adjustable low idle
speed
Low idle speed adjustment switch
---------------------------------------------------------------
Low idle speed
Disable
--------------------
700 RPM
Switched maximum
engine operating speed
Switched maximum engine operating speed
---------------------------------------------------------------
Maximum operating speed switch setup
---------------------------------------------------------------
Maximum switched engine speed
Enable
--------------------
Active closed
--------------------
900 RPM
