148 Troubleshooting
Figure 8-1
Digital Multimeter or VOM (Volt-Ohm-Milliammeter)
NOTE: The ammeter must support at least 10 amps.
Figure 8-2
Jumper wire with alligator clips
Figure 8-3
Two 0–4000 PSI oil pressure gauges (left), ball-end hex wrench (metric and SAE) [right]
0–4000 PSI
pressure gauge
(Part# HYF00910)
Female
quick coupler
(Part# HYF10195)
