Page #158 background imageLoading...
Page #158 background image
152 Troubleshooting
Packer moves forward but
stops at the end of stroke
Packer wear plates are worn out Replace wear plates. See Replacing
Packer Wear Plates on page 37
Packer extend limit/proximity
switch is misaligned
Adjust switch. See Adjusting Packer
Extend Proximity Switch on page 48
Packer does not perform
enough cycles
Multicycle module
programming
Reprogram the module for higher
number of cycles (see Multicycle on
page 175).
Backup alarm and warning
buzzer inside the cab sound
all the time
Misaligned tailgate proximity
switch
Adjust tailgate proximity switch (see
Adjusting Tailgate Unlocked
Proximity Switch on page 53).
Faulty proximity switch Check the proximity switch with a
multimeter or
VOM for proper
operation (O
N/OFF or click).
Replace if necessary.
Faulty harness Check for continuity on the
electrical harness that is connected
to the proximity switch. Change the
electrical harness if necessary.
Arm is too fast/too slow Flow limiter adjustment on arm
control valve
Recalibrate cylinder speed (see
Adjusting Arm Speed on page 200).
Flashing lights on
dashboard always blinking
Misaligned arm stowed limit
switch
Align switch lever with gripper
finger (see Adjusting Arm Stowed
Limit Switch on page 62).
Cut off or defective power
cables
Perform a continuity test on the
cable. Replace faulty cables if
necessary.
Faulty limit switch Replace faulty limit switch.
Arm does not respond to
joystick (assuming that
PTO
switch is engaged)
Cut off or defective power
cables
Follow wires on the electrical
schematic for 12-volt supply (move
joystick to get signal).
Faulty joystick Contact LabriePlus.
Problem Possible causes Solution
