Lifting Arm 193
Figure 10-4
Connections
Figure 10-5
Wear pads
5. Check for loose nuts and bolts.
Figure 10-6
Bolts
6. Check the arm stowed limit switch.
For more information, see Adjusting Arm Stowed Limit Switch on page 62.
7. Lubricate the arm moving parts as per the Arm Lubrication Chart on page 76.
8. Lock out and tag out the vehicle (see Locking Out and Tagging Out the Vehicle on page 20).
