Safety 19
Figure 2-13
Suction line shut-off valve
3. Start the engine.
Once the engine is started, wait for the air pressure to build up to at least 70 PSI.
Figure 2-14
Air pressure indicator
IMPORTANT: Do not operate or move the vehicle until the air pressure has reached 70 PSI.
4. Engage the hydraulic system by switching ON the Pump ON/OFF switch on the in-cab control
panel (see Figure 2-15).
The switch will turn from blue to green.
Warning!
Failure to fully open the main valve will cause immediate damage to the pump, even if
the pump is turned off.
To Next Page
