General Maintenance 53
Figure 3-40
Tailgate proximity switch (locked position)
Figure 3-41
Tailgate proximity switch (unlocked position)
To adjust the tailgate unlocked proximity switch:
1. Start the engine and engage the hydraulic system.
2. Loosen the nuts located on each side of the proximity switch bracket (see Figure 3-42).
NOTE: The second nut is on the hidden side of the body wall.
Plate
Proximity
switch
Plate
Proximity
switch
