Labrie MINIMAX Maintenance Manual

64 General Maintenance
The ARM EXTENDED warning light should go off when the arm is in a parked travel position
(see Figure 3-52).
Figure 3-53 Arm Parked limit switch
Figure 3-54 Helping-Hand
TM
arm base
Figure 3-55 Arm Parked limit switch adjustment
Top cover plate
Curved cover plate
Detection lever
Screws
