Labrie MINIMAX Maintenance Manual

Lubrication 75
Figure 4-9 Lubrication chart - M INIMAX ™
TAILGATE CYLINDER UPPER PIN
TAILGATE HINGES
HOPPER DOORS HINGES
CLEANING TRAP DOOR HINGES
FOLLOWER PANEL ROLLERS
PACKER CYLINDER REAR PIN
PACKER CYLINDER FRONT PIN
TAILGATE PINS
NO. DESCRIPTION
FREQUENCY
1
2
3
4
5
6
7
8
9
LUBRICATION CHART, MINIMAX
TAILGATE CYLINDER LOWER PIN
* REFER TO MAINTENANCE MANUAL FOR PROPER LUBRICANT
LUBRICATION CHART *
WEEKLY
WEEKLY
WEEKLY
WEEKLY
WEEKLY
WEEKLY
WEEKLY
WEEKLY
TWO TIMES/WEEK
1
2
3
4
7
5
9
6
8
VIEW FROM
UNDERNEATH
THE PACKER
VIEW FROM
UNDERNEATH
THE PACKER
VIEW FROM
LEFT-HAND SIDE
SEE DETAIL (A)SEE DETAIL (A)
DETAIL (A)
