Ecovip series
Through a trap door in the floor, near the rear bed, it is
possible to reach the tap (a) and the probes (b).
By rotating the tap (a) by half a turn there will be a
drainage to the level of 20% of the total capacity, whilst
rotating by a whole turn there will be a 100% drainage.
Outside, on the left hand side, there is the cap (c) for
access to the inspection cap (d).
14 - WATER SYSTEM (ECOVIP - KREOS)
USER’S GUIDE
77
The tap (a) must be rotated a turn at the most.
WARNING
a
b
c
d
