Lantech IPES-5408T User Manual

8
Protocol
CSMA/CD
LED
Per unit: Power 1 (Green), Power 2 (Green), P-Fail (Red)
Ethernet port: Link/Activity (Green), Speed (Green); GigaT: Link/Activity (Green)
DI / DO
1 Digital Input (DI) :
Level 0: -30~2V / Level 1: 10~30V
Max. input current:8mA
1 Digital Output(DO): Open collector to 40 VDC, 200mA
Operating Humidity
5% ~ 95% (Non-condensing)
Operating Temperature
-40°C~75°C / -40°F~167°F
Storage Temperature
-40°C~85°C / -40°F~185°F
Redundant Power Supply
Standard model:
12~72VDC
-48VDC is available for single power input
Power Consumption
Max 10W
Case Dimension
IP67 model: Aluminum case
215mm(W)x201.4mm(H)x77.6mm(D)
IP43 model: Aluminum case
203mm(W)x188.4mm(H)x77.6mm(D)
Weight
1.3kgs(IP67). 1.1(IP43)
Installation
DIN Rail** and Wall Mount Design
EMI & EMS
FCC Class A,
CE EN61000-6-2, CE EN61000-6-4, CE EN61000-4-2, CE EN61000-4-3, CE EN61000-4-4, CE EN61000-4-5, CE EN61000-4-6,
CE N61000-4-8, EN61000-4-11
Stability Testing
IEC60068-2-32 (Free fall), IEC61373 (Shock),
IEC61373 (Vibration)
MTBF
n/a
Warranty
5 years
Software Specification
Management
SNMP v1 v2c, v3/ Web/Telnet/CLI
SNMP MIB
RFC 1215 Traps MIB,
RFC 1213 MIBII
RFC 1158 MIBII
RFC 1157 SNMP MIB,
RFC 1493 Bridge MIB,
RFC 1573 IF MIB
RFC 2674 VLAN MIB,
RFC 1643 EtherLike,
RFC 1757 RMON,
RFC 2674 Q-Bridge MIB
RFC 2790 Host Resource MIB
RSTP MIB*
LLDP MIB*
Private MIB
ITU G.8032
Support ITU G.8032 v2 for Ring protection in less than 20ms for self-heal recovery < 256 switches
Support various ring/chain topologies
Ring covers data & multicast* packets
Co-exist with RSTP on different ports
User friendly UI
 Auto topology drawing
 Topology demo
 Auto configuration for G.8032 single ring
Port Trunk with LACP
LACP Port Trunk: 4 Trunk groups/Maximum 4 trunk members
Link aggregation to increase bandwidth
LLDP
Supports LLDP to allow switch to advise its identification and capability on the LAN
CDP
Cisco Discovery Protocol for topology mapping
VLAN
Port Based VLAN
IEEE 802.1Q Tag VLAN (256 entries)/ VLAN ID (Up to 4K, VLAN ID can be assigned from 1 to 4096.)
GVRP (256 Groups)*,GMRP*, QinQ*
IPv6/IPv4
Present
Spanning Tree
Supports IEEE802.1d Spanning Tree and IEEE802.1w Rapid Spanning Tree, IEEE802.1s Multiple Spanning Tree
Quality of Service
The quality of service determined by port, Tag and IPv4 Type of service, IPv4 Different Service
Class of Service
Support IEEE802.1p class of service, per port provides 8 priority queues
IP Security
Supports 10 IP addresses that have permission to access the switch management and to prevent unauthorized intruder.
Login Security
Supports IEEE802.1X Authentication/RADIUS
Port Mirror
Support 3 mirroring types: “RX, TX and Both packet”
Network Security
Support 10 IP addresses that have permission to access the switch management and to prevent unauthorized intruder.
802.1X access control for port based and MAC based authentication/MAC-IP-Port binding
Management access control with priority
256 Policy based Access Control List
SSL/ SSH for Management
TACACS+ for Authentication*
IGMP
Support IGMP snooping v1,v2,v3; Supports IGMP static route; 256 multicast groups; IGMP router port ; IGMP query
Multicast VLAN Registration
MVR enables multicast packets go through VLAN for VOD application
Bandwidth Control
Support ingress packet filter and egress packet limit.
The egress rate control supports all of packet type.
