Lantech IPES-5408T User Manual

7
Chapter 1 Introduction
Lantech IES-5408T & IPES-5408T (IP67/IP43) series is a high performance L2
+
IP67/IP43 industrial Gigabit uplink switch with 8x10/100TX + 4 GigaT (w/8 PoE at/af
injectors-IPES model)by M12 connectors which provides L2 wire speed and advanced
security function for connecting PD network. It delivers ITU G.8032 ring recovery less
than 20ms, comprehensive QoS, , IGMPv1/v2/v3 & router port, QinQ*(double tag
VLAN) , MVR (multicast VLAN registration) , LACP link aggregation and advanced
security including ACL, TACAS+*, SSH/SSL, DHCP Option 82*which are important
features required in large network. It also supports Cisco Discovery Protocol (CDP) and
LLDP for Ciscoworks to detect the switch info to be shown on L2 map topology. The
user friendly UI, innovative auto topology drawing and topology demo makes IES-5408T
& IPES-5408T (IP67/IP43) series much easier to get hands-on. The complete CLI allows
professional engineer to configure by command line.
Specification
IES-5408T series
Hardware Specification
Standards
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX
IEEE 802.3ab 1000Base T
IEEE802.3x Flow Control and Back Pressure
IEEE802.3ad Port trunk with LACP
IEEE802.1d Spanning Tree
IEEE802.1w Rapid Spanning Tree
IEEE802.1s Multiple Spanning Tree
IEEE 802.3ad Link Aggregation Control Protocol (LACP)
IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
IEEE 802.1X User Authentication (Radius)
IEEE802.1p Class of Service
IEEE802.1Q VLAN Tag
Switch Architecture
Back-plane (Switching Fabric): 9.6Gbps
Packet throughput ability (Full-Duplex): 23.8Mpps @64bytes
Transfer Rate
14,880pps for Ethernet port
148,800pps for Fast Ethernet port
1,488,000pps for Gigabit port
Mac Address
16K MAC address table
Jumbo frame
10KB for 10/100TX ports
Connector
10/100TX: 8 x M12 4-pole D-coded with auto MDI/MDI-X function
10/100/1000T: 4 x M12 8-pole A-coded with auto
MDI/MDI-X function
RS-232 connector: 1 x M12 5-pole A-coded
Power Input connector : 1 x M12 5-pole A-coded
Relay contact : 1 x M12 5-pole A-coded
Network Cable
10Base-T: 2-pair UTP/STP Cat. 3, 4, 5 cable
EIA/TIA-568 100-ohm (100m)
100Base-TX: 2-pair UTP/STP Cat. 5/ 5E cable
EIA/TIA-568 100-ohm (100m)
1000BaseT : 4-pair UTP/STP Cat. 5E/ 6 cable
EIA/TIA-568 100-ohm (100m)
