Proline Kryomats
YAUE0007 / 2/26/2009 Starting up 37
3. Super window with seven items of
information:
− T
int
, current bath temperature.
− T
set
, setpoint.
− T
ext
, current temperature on external probe
(if connected).
− Overtemperature cut-off point T
max
.
− Pump level of the VarioFlex Pump.
− Control variable to T
int
or T
ext
.
− Information: Heating / cooling.
Soft keys like above.
4. Graphical measurement display
− All temperature values can be shown
graphically against time Ö 7.7.
− Soft keys like above.
Hel
Menu Screen T
set
T
fix
T
int
°C
25,01
T
set
°C
25,00
T
max
°C
130
Pump
3
Control Var.
T
int
T
ext
°C
25
02
55,3
Y(%)
0,0
