LAUNCH PAD V
User's Manual
Lens Diameter 7.0mm
Probe Tube Diameter 6.0mm
Viewable Angle 60
o
Lens Focal Length More than 50mm
Net Weight Approx. 270g
7.5.4 Connections & Operations
1. Insert the data cable into the data I/O port of the diagnostic tool.
2. Bend the neck of the flexible tube as desired and extend the
camera with adjustable LED lights to some unseen or unreachable
parts of engine, hydraulic system, nozzles etc.
3. After connections are properly made, press the [POWER] button
on the tablet to turn it on. Wait until the system enters the Home
screen.
4. Tap the application to launch it. Switch to the "Toolbox" ->
"Videoscope" to run it, and then the screen will display the scene
captured from the videoscope camera.
5. Adjust it until the lens stops in the desired place, then use the dial
for LED light brightness to adjust the brightness.
6. Press the Snapshot button on the videoscope to take a photo.
Alternatively, you can also press the Snapshot button on the tablet
to take photos.
To record a video, switch from Camera mode to Video mode and
tap the Record button on the screen to start recording.
Images are captured in .jpg format and videos are recorded in .avi or
.mp4 format. All photographings and videos are saved in DCIM folder
where users can browse and replay it.
