LAUNCH PAD V
User's Manual
17
For non-OBDII vehicle, proceed as follows:
1. Locate vehicle’s DLC socket.
2. Select the corresponding non-16pin dongle.
3. Plug the non-16pin end of the non-16pin adaptor into the DLC
socket, then connect the other end to the OBD I adaptor, and then
tighten the captive screws.
4. Connect the other end of the adaptor to the included VCI device.
5. To supply power to OBD I adaptor from:
A. Cigaretter Lighter: Connect one end of the cigarette lighter cable
to vehicle’s cigarette lighter receptacle, and the other end to the
DC-IN jack of the VCI device.
VCI device
Cigarette lighter
OBD I adaptor Non-16pin adaptor
To vehicle's DLC
To Cigarette lighter receptacle
Fig. 5-2
B. Battery Clamps Cable: Connect one end of the battery clamps
cable to vehicle’s battery, and the other end to the power jack of
OBDI adaptor.
VCI device
Battery clamps cable
OBD I adaptor Non-16pin adaptor
To vehicle's DLC
To vehicle's battery
Fig. 5-3
5.1.3 Vehicle Connection (For Commercial Vehicle Version/
Diesel & Gasoline Version)
The method used to connect the VCI device to a vehicle’s DLC
depends on the vehicle’s confi guration as follows:
For OBD II vehicle, directly plug the VCI device into the vehicle’s DLC
(OBD II extension cable is recommended).
For non-OBD II vehicle, follow either of the ways to proceed:
1. Locate vehicle’s DLC socket.
2. Select the corresponding non-16pin dongle.
3. Plug the non-16pin end of the non-16pin adaptor into the DLC
socket, then connect the other end to the OBD II extension cable.
4. Connect the other end of the adaptor to the included VCI device.
5. To supply power to OBD I adaptor from:
A. Cigaretter Lighter: Connect one end of the cigarette lighter cable
to vehicle’s cigarette lighter receptacle, and the other end to the
DC-IN jack of the VCI device.
To Next Page
