LAUNCH PAD V
User's Manual
3
2 Components & Controls
There are three main components to the diagnostic system:
• Display Tablet -- the central processor and monitor for the system
(For details, please refer to Chapter 2.1.)
Fig. 2-1
• Docking Station -- the platform for charging the tablet and extending
functions (For details, please refer to Chapter 2.2.)
Fig. 2-2
• VCI Device -- the device for accessing vehicle data (For details,
please refer to Chapter 2.3.)
Fig. 2-3
