39. SPECIFICATION - MANAGERS CALLPOINT
Tynetec Part No’s
ZXT250 Standard, ZXT255 Custom Engraved
EMC Approval
EN 55022
Safety Approval
EN 60950
Data Connection
RS485 (19200 Baud)
Power Requirement
24V DC @ 2mA (standby)
Audio Channel
Handsfree Voice Switched
8 Way Address DIL Switch
Set Binary ID
8 Way Options DIL Switch
Set 1-8 OFF (not used)
3 Jumpers
Fit LK1 in Position B & LK2/LK3 both in Position A
Loudspeaker
35 Ohm 0.5 Watts
Features
Flush Mount
Standard
Surface Mount
Optional HM1125 Surface Cowling required
Rain Hood
Optional HM1116 Flush Cowling required
Pushbutton
Vandal Resistant (Bulgin Type MP0037)
Loudspeaker
Protected by Fine Mesh Stainless Steel Grill
Microphone
Protected by Fine Mesh Stainless Steel Grill
DDA Compliance
High Visibility Yellow Halo around Pushbutton
Engraving
ZXT250: MANAGER (Black infill, 5mm high), ZXT255: Custom Engraved
Audible Reassurance
Yes - integral Piezo Beeper 4kHz 75dB @ 1m
Relay Output
Yes - 1 x N/O (contacts rated 30V DC @ 1A)
Fixings
4 No. M5 x 12mm Countersunk Allen Head Bolts
Fixing Tool
3mm Allen Key
Mechanical
Fascia Material
12 SWG Stainless Steel
Fascia Dimensions
200mm x 160mm x 2.64mm (HxWxD)
Bezel Material
18 SWG Stainless Steel
Bezel Dimensions
14mm Wide
Backbox Material
16 SWG Galvanized Mild Steel
Backbox Dimensions
200mm x 160mm x 50mm (HxWxD)
Ingress Protection Rating
IP44
Weight
1.72 kg (inc Backbox)
Environmental
Operating Temperature
0
o
C to +40
o
C
Operating Humidity
10% to 90% RH
Relative Humidity
Non-condensing
