Service Manual JET3
190 Rev. 1.0
Disconnect the socket KL 1 for the hydraulic connection
Disconnect the socket KL 2 for the optional hydraulic connection
Information
The procedure for disconnect KL 2 is just the same like for KL 1
Place the assembly tool
exactly in the middle
of the connector.
Push them carefully
inside between the
socket and the plug.
Pull the plug out
of the socket by
a slotted screwdriver.
Assembly tool.
Slotted screwdriver.
