Service Manual JET3
Rev. 1.0 191
7. Remove the screw connections in front of the board.
After all wire connections are disconnected you can unscrew the screws and the
thread bolts of the board from the front side.



2x thread bolt.
4x screw M4.
Remove the 4x screws
with an allen key
(SW 2,5 mm).
Remove the 2x thread
bolts with a jaw
spanner (SW 5,5 mm).
