Leica mojo3D, Running the mojo3D for the First Time 43
Section controller
implement mode
setup,
step-by-step
1. On the section controller/implement mode setup screen, in the list at the left of
the screen, tap to select section controller type:
• None: section control is disabled.
• On Screen: sections are shown on screen turning on & off, but no physical
control of sections is possible.
• Single Section: a maximum of one section can be setup for the vehicle. This
section is automatically controlled with physical output on the port expansion
cable.
• Leica AS400: multiple sections are automatically controlled via the Leica
AS400 section controller hardware, supplied with the multi-section control kit.
If Direct Section Control has been unlocked, other Section Controllers will
appear in the list.
2. Tap to select implement mode:
• Sprayer Mode: is used for most situations, this allows the section control to
be optimally setup for general applications.
• Planter Mode: optimises the system for operating a planter and if selected,
reverses the polarity of the Leica AS400 normal operation.
3. Tap to continue.
Master input
source setup,
step-by-step
1. On the master input source screen, in the list at the left of the screen, tap to
select the master input source.
2. In the list at the right of the screen, tap to select the input mode.
