InstallingtheRAIDcard
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage83.
ThistopicprovidesinstructionsonhowtoinstalltheRAIDcard.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•UseanydocumentationthatcomeswiththeRAIDcardandfollowthoseinstructionsinadditionto
theinstructionsinthistopic.
•EnsurethatyoubackupyourdatabeforeinstallingtheRAIDcardbecauseyoumightneedtoreconfigure
RAIDandreinstalltheoperatingsystemafterinstallingtheRAIDcard.
•Ifyourserverhasonemicroprocessorinstalled,itisrecommendedthattheRAIDcardbeinstalledintothe
PCI-Eslot5orPCI-Eslot2.Ifyourserverhastwomicroprocessorsinstalled,itisrecommendedthat
theRAIDcardbeinstalledintothePCI-Eslot4.
ToinstalltheRAIDcard,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage85.
3.Laytheserveronitssideforeasieroperation.
4.LocatetheappropriatePCI-Eslotonthesystemboard.See“Systemboardcomponents”onpage48.
5.Removeanypartsordisconnectanycablesthatmightimpedeyouroperation.
6.Touchthestatic-protectivepackagethatcontainstheRAIDcardtoanyunpaintedsurfaceonthe
outsideoftheserver.Then,taketheRAIDcardoutofthepackage.
Note:CarefullyhandletheRAIDcardbyitsedges.
7.InstalltheRAIDcard.TheprocedureissimilartothatoftheEthernetcard.See“InstallingtheEthernet
card”onpage100.
8.ConnectsignalcablestotheconnectorsonthenewRAIDcardandtheconnectorsonthehot-swap
hard-disk-drivebackplanes.See“Connectingthecables”onpage43.
9.InstallthePCIcardbracketassemblythatcomeswiththeRAIDcard.See“Removingandreinstalling
thePCIcardbracketassembly”onpage89.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage200.Then,configure
RAIDforyourserver.See“ConfiguringRAID”onpage72
.
•AfteraLenovoRAIDcardisinstalled,dothefollowing:
1.ChecktheversionofthenewRAIDcardfirmwarebypressingCtrl+HwhenstartingtheSetup
Utilityprogram.
2.Gotohttp://www.lenovo.com/driversandfollowtheinstructionsontheWebpagetodownloadthe
latestversionoffirmware.Then,installthefirmwaretoyourserver.
Note:IfyouwanttousetheFirmwareUpdaterprogram,ensurethatitisthelatestversion.Togetthe
latestversionoftheFirmwareUpdaterprogram,gotohttp://www.lenovo.com/drivers,locatedifferent
versionsoftheprogram,andthenidentifythelatestversionbycomparingreadmefiles.Ifthelatest
Chapter6.Installing,removing,orreplacinghardware105
