•IfyouarereplacinganRDXdriveandareinstructedtoreturntheoldRDXdrive,followallpackaging
instructionsanduseanypackagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage200
.
Connectinganexternaltapedrive
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage83.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•Dependingonthemodel,yourtapedrivemightlookslightlydifferentfromtheillustrationsinthistopic.
•Useanydocumentationthatcomeswiththetapedriveandfollowthoseinstructionsinadditionto
theinstructionsinthistopic.
Toconnectanexternaltapedrive,dothefollowing:
1.Turnofftheserveranddisconnecttheserverfromtheacpowersource.
2.Connectoneendofamini-SASsignalcabletothemini-SASconnector1ontherearoftheexternal
tapedrive.
Figure97.Mini-SASconnector1ontheexternaltapedrive
3.Connecttheotherendofthemini-SASsignalcabletoanavailablemini-SASconnectorprovidedby
theHostBusAdapterinstalledinyourserver.
4.Connecttheexternaltapedrivetoanacpowersource.Then,turnonthetapedriveifnecessary.
5.Connecttheservertoanacpowersourceandturnontheservertoverifyifthetapedriveworkscorrectly.
Installingorreplacingthemicroprocessor
Thistopicprovidesinstructionsonhowtoinstallorreplacethemicroprocessor.
Installingthesecondmicroprocessor
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage83.
Thistopicprovidesinstructionsonhowtoinstallthesecondmicroprocessor.
Chapter6.Installing,removing,orreplacinghardware157
