Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheremovalprocedure,goto“Completingthepartsreplacement”onpage200
.Asthe
onboardSATAorSASsoftwareRAID5isnotavailablewithouttheTR100orTR300Key,youmightneed
toreconfigureRAIDforyourserver.See“ConfiguringRAID”onpage72.
InstallingorremovingtheThinkServerManagementModulePremium
ThistopicprovidesinstructionsonhowtoinstallorremovetheThinkServerManagementModulePremium
(hereinafterreferredtoastheTMMPremium).
TheTMMPremiumoffersconvenient,remoteKVMaccessandcontrolthroughtheLANorInternet.You
canusetheTMMPremiumtogainlocation-independentremoteaccesstorespondtocriticalincidentsand
toundertakenecessarymaintenance.Therefore,workingasanintegratedsolutioninyourserver,the
TMMPremiumprovidesanincreasedlevelofmanageabilityoverthebasicservermanagementavailable.
YoucanpurchaseaTMMPremiumfromLenovo.
InstallingtheTMMPremium
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage83.
ThistopicprovidesinstructionsonhowtoinstalltheTMMPremium.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•UseanydocumentationthatcomeswiththeTMMPremiumandfollowthoseinstructionsinadditionto
theinstructionsinthistopic.
•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationinthistopic.
ToinstalltheTMMPremium,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage85.
3.Laytheserveronitssideforeasieroperation.
4.Touchthestatic-protectivepackagethatcontainstheTMMPremiumtoanyunpaintedsurfaceonthe
outsideoftheserver.Then,taketheTMMPremiumoutofthepackage.
116ThinkServerTD340UserGuideandHardwareMaintenanceManual
