6.Removetheoldsystemboardbattery.
Figure130.Removingthesystemboardbattery
7.Installanewsystemboardbattery.
Figure131.Installingthesystemboardbattery
8.ReinstallthePCIExpresscard(suchastheEthernetcard)thathasbeenremoved.See“Installingthe
Ethernetcard”onpage100.
9.Disposeoftheoldsystemboardbatteryasrequiredbylocalordinancesorregulations.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage200.Afteryoureplace
thesystemboardbattery,youmustresetpasswords,resetsystemdateandtime,andreconfigurethe
server.SeeChapter5“Configuringtheserver”onpage61
.
Replacingthesystemboard
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage83.
Thistopicprovidesinstructionsonhowtoreplacethesystemboard.
Note:ThisproceduremustbeperformedonlybytrainedservicepersonnelofLenovo.
CAUTION:
Hazardousmovingparts.Keepfingersandotherbodypartsaway.
