Thefollowingillustrationshowstheconnectorsontheexpandercard.Eachconnectorontheexpander
cardisusedtoconnectamini-SAStomini-SASsignalcable.Fordetailedinformation,see“Connecting
thecables”onpage43
.
Figure20.Expandercard
1Connector14Connector4
2Connector25Connector5
3Connector36Connector6
Hot-swaphard-disk-drivebackplane
Yourservercomeswithoneofthefollowinghot-swapharddiskdriveandbackplaneconfigurations:
•Uptofour3.5-inchhot-swapSATAorSASharddiskdriveswithonebackplane
•Fivetoeight3.5-inchhot-swapSATAorSASharddiskdriveswithtwobackplanes
•Uptoeight2.5-inchhot-swapSASharddiskdrivesorSATAsolid-statedriveswithonebackplane
•Ninetosixteen2.5-inchhot-swapSASharddiskdrivesorSATAsolid-statedriveswithtwobackplanes
Chapter3.Productoverview39
