Lenovo ThinkServer TD340 - Installing or Removing the Thinkserver RAID 500 Upgrade Key for Advanced RAID

•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheremovalprocedure,goto“Completingthepartsreplacement”onpage200.Then,you
needtoreconfigureRAIDforyourserver.See“ConfiguringRAID”onpage72.
InstallingorremovingtheThinkServerRAID500UpgradeKeyfor
AdvancedRAID
ThistopicprovidesinstructionsonhowtoinstallorremovetheThinkServerRAID500UpgradeKeyfor
AdvancedRAID(hereinafterreferredtoastheTR500Key).
TheTR500KeyexpandsthecapabilityoftheinstalledThinkServerRAID500AdapterbyactivatingRAID5
andRAID50levelsforadvancedSATA/SAShardwareRAID.YoucanpurchaseaTR500KeyfromLenovo.
InstallingtheTR500Key
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiii
and“Guidelines”onpage83.
ThistopicprovidesinstructionsonhowtoinstalltheTR500KeyonaThinkServerRAID500Adapterif
yourserverhasoneinstalled.
Attention:BackupyourdatabeforeyoubeginifyouwanttoreconfigureRAIDandreinstalltheoperating
systemafterinstallingtheTR500Key.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:UseanydocumentationthatcomeswiththeTR500Keyandfollowthoseinstructionsinadditionto
theinstructionsinthistopic.
ToinstalltheTR500Key,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage85.
3.Laytheserveronitssideforeasieroperation.
4.LocatetheThinkServerRAID500Adapterandremoveanypartsordisconnectanycablesthatmight
impedeyouroperation.
5.Touchthestatic-protectivepackagethatcontainstheTR500Keytoanyunpaintedsurfaceonthe
outsideoftheserver.Then,taketheTR500Keyoutofthepackage.
Note:CarefullyhandletheTR500Keybyitsedges.
Chapter6.Installing,removing,orreplacinghardware107
