Lenovo ThinkServer TD340 - Front Panel

Frontpanel
Thistopicprovidesinformationtohelpyoulocatethecontrol,connectors,andLEDsonthefrontpanelof
theserver.
Thefollowingillustrationshowsthecontrol,connectors,andLEDsonthefrontpaneloftheserver.
Note:Dependingonthemodel,yourservermightlookslightlydifferentfromthisillustration.
Figure4.Frontpanel
1PowerswitchwithpowerstatusLED
5SystemstatusLED
2HarddiskdrivestatusLED
6FrontUSBconnector1
3NetworkInterfaceController(NIC)1statusLED7FrontUSBconnector2
4NIC2statusLED
1PowerswitchwithpowerstatusLED
Pressthepowerswitchtoturnontheserverwhenyoufinishsettinguptheserver.Holdthepowerswitch
forseveralsecondstoturnofftheserverifyoucannotturnitofffromtheoperatingsystem.SeeChapter
4“Turningonandturningofftheserver”onpage59
.ThepowerstatusLEDhelpsyoutodeterminethe
currentpowerstatus.
Chapter3.Productoverview17
