24InternalUSBTypeAconnector
UsedtoconnectadevicethatusesaUSBTypeAconnector.Forexample,insomesituations,youmight
wanttoconnectaUSBkeydirectlytothesystemboard.Inthiscase,youcanconnectittoaninternal
USBTypeAconnector.
25TMMPremiumconnector
UsedtoconnectaserveroptionnamedThinkServerManagementModulePremium(TMMPremium)to
enableadvancedremotemanagementfunctionsonyourserver.See“InstallingorremovingtheThinkServer
ManagementModulePremium”onpage116.
26TPMconnector
UsedtoconnectaThinkServerTrustedPlatformModule(TPM),whichisasecuritychip,toenhanceserver
security.See“InstallingorremovingtheThinkServerTrustedPlatformModule”onpage119.
27IntelligentDiagnosticsModuleconnector
UsedtoconnectthecableoftheIntelligentDiagnosticsModule.
28Frontpanelconnector
Usedtoconnectthefrontpanelcable.
29InternalUSBconnector5-6
30InternalUSBconnector7-8
UsedtoconnectthefrontpanelUSBcables.
31Systemboardbattery
Yourserverhasaspecialtypeofmemorythatmaintainsthedate,time,andconfigurationinformationfor
built-infeatures.Thesystemboardbatterykeepstheinformationactivewhenyouturnofftheserver.
33PCIcardslot(PCIslot1)
Usedtoinstallastandard32-bit33MHzPCIcardwith167mm(6.57inches)inlength.
34PCIExpressx8cardslot(PCI-Eslot2)
ThisPCIcardslotsupportsaPCIExpressx8card(negotiablelinkwidthx4)with167mm(6.57inches)in
length,suchasanEthernetcard.
35PCIExpressx8cardslot(PCI-Eslot3)
ThisPCIcardslotsupportsaPCIExpressx8cardwith167mm(6.57inches)inlength,suchasanEthernet
card.
Chapter3.Productoverview51
