3Opticaldrivebay1
Yourservercomeswithanopticaldriveinstalledinthe5.25-inchopticaldrivebay1.
4Opticaldriveeject/closebutton
Pressthisbuttontoejectorclosetheopticaldrivewhentheserverpowerison.
5OpticaldrivestatusLED
TheopticaldrivestatusLEDisblinkingingreenwhentheopticaldriveisworkingorinthePOSTprocess.
6Frontdoor
7Frontdoorlock
Youcanlockthefrontdoortoprotectthehard-disk-drivecagesfromunauthorizedaccess.
8Frontdoorhandle
Usethefrontdoorhandletoopenthefrontdoor.
9Intelligentdiagnosticsmodulepanel
Theintelligentdiagnosticsmodulepanelisonlyavailableinmodelsthatcomewithanintelligentdiagnostics
module.Formoreinformation,see“Intelligentdiagnosticsmodule”onpage19.
16ThinkServerTD340UserGuideandHardwareMaintenanceManual
