Notes:
•IfyouremovetheTR100orTR300Key,theonboardSATAorSASsoftwareRAID5willbedisabled
correspondingly.
•UseanydocumentationthatcomeswiththeTR100orTR300Keyandfollowthoseinstructionsin
additiontotheinstructionsinthistopic.
•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationinthistopic.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
ToremovetheTR100orTR300Key,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage85.
3.Laytheserveronitssideforeasieroperation.
4.LocatetheiButtonsocketonthesystemboard.
5.Opentheretainingclip1ontheiButtonsockettoreleasetheTR100orTR300Key,andthen
completelyremovethekeyfromtheiButtonsocket.
Figure57.RemovingtheTR100orTR300Key
6.IfyouareinstructedtoreturntheoldTR100orTR300Key,followallpackaginginstructionsanduse
anypackagingmaterialsthataresuppliedtoyouforshipping.
