6.InsertonesideoftheTR100orTR300KeyunderoneoftheretainingclipsontheiButtonsocket.Then,
carefullypresstheothersideoftheTR100orTR300Keystraightdownuntilthekeysnapsintoposition
andissecuredbythetworetainingclipsontheiButtonsocket.
Figure56.InstallingtheTR100orTR300Key
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage200
.Then,theonboard
SATAorSASsoftwareRAID5isavailableforyourserverifyourserverhastherequirednumberofhard
diskdrivesinstalled.ToconfigureRAID,see“ConfiguringRAID”onpage72.
RemovingtheTR100orTR300Key
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage83.
ThistopicprovidesinstructionsonhowtoremovetheTR100orTR300Keyifyourserverhasoneinstalled.
