fortheonboardSATAorSASsoftwareRAIDcorrespondingly.YoucanpurchaseaTR100orTR300Key
fromLenovoandinstallittotheiButtonsocketonthesystemboard.
ThistopicprovidesinstructionsonhowtoinstallorremovetheTR100orTR300Key.
InstallingtheTR100orTR300Key
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage83.
ThistopicprovidesinstructionsonhowtoinstalltheTR100orTR300Key.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•UseanydocumentationthatcomeswiththeTR100orTR300Keyandfollowthoseinstructionsin
additiontotheinstructionsinthistopic.
•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationinthistopic.
ToinstalltheTR100orTR300Key,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage85.
3.Laytheserveronitssideforeasieroperation.
4.LocatetheiButtonsocketonthesystemboard.
5.Touchthestatic-protectivepackagethatcontainstheTR100orTR300Keytoanyunpaintedsurface
ontheoutsideoftheserver.Then,taketheTR100orTR300Keyoutofthepackage.
Chapter6.Installing,removing,orreplacinghardware113
