•IfyouareinstallinganRDXdrive,removethefrontbezel.See“Removingandreinstallingthefront
bezel”onpage87
.Then,removetheplasticshieldforthebayfromthefrontpanel.Removethe
screw1thatsecuresthemetalEMIshieldcoveredontheopticaldrivebay.Insertafingerintothe
holeintheEMIshieldandcarefullypulltheEMIshieldoutofthefrontofthechassis.
Figure93.RemovingtheEMIshieldfortheopticaldrivebay
154ThinkServerTD340UserGuideandHardwareMaintenanceManual
