CAUTION:
Hazardousmovingparts.Keepfingersandotherbodypartsaway.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
•Useanydocumentationthatcomeswiththenewfrontsystemfan1andfollowthoseinstructionsin
additiontotheinstructionsinthistopic.
Toreplacethefrontsystemfan1,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage85.
3.Locatethefrontsystemfan1.See“Servercomponents”onpage28.
4.Disconnectthefrontsystemfan1cablefromthesystemfan1connectoronthesystemboard.See
“Systemboardcomponents”onpage48.
5.Pressthetwotabsofthefrontsystemfan1towardseachotheruntilthetwotips1arealignedwiththe
correspondingholesinthechassis.Then,carefullyslidethefrontsystemfan1outofthechassis.
Figure124.Removingthefrontsystemfan1
184ThinkServerTD340UserGuideandHardwareMaintenanceManual
