b.Positionthemicroprocessorsocketcoverabovethemicroprocessorsocketsothatthesmalltriangle
1onthesocketcoverfacesthesmalltriangle2onthemicroprocessorretainer.Then,carefully
pressthesocketcoverstraightdownintothesocketuntilitsnapsintoposition.
Figure136.Installingthemicroprocessorsocketcover
c.Gentlyclosethemicroprocessorretainer,pressdownthesmallhandle,andthenpushthesmall
handleinwardtolocktheretainerintoposition.
Figure137.Securingthemicroprocessorretainer
20.Installallpartsthatyouhaveremovedandconnectallcablestothenewsystemboard.Refertothe
informationthatyouhaverecordedandtherelatedtopicsinChapter6“Installing,removing,orreplacing
hardware”onpage83
.
21.Ifyouareinstructedtoreturntheoldsystemboard,followallpackaginginstructionsanduseany
packagingmaterialsthataresuppliedtoyouforshipping.
Chapter6.Installing,removing,orreplacinghardware199
