Thefollowingillustrationshowstherearviewoftheserverwithascrew-secured,non-hot-swappower
supplyassembly.
Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
Figure6.Rearviewoftheserverwithanon-hot-swappowersupplyassembly
1Powercordconnector
6VGADB-15connector
2Serialconnector
7IDLED
3USBconnectors(4)
8Expansioncardarea
4Ethernetconnector1forsystemmanagement
(RJ-45)
9Frontdoorkey
5Ethernetconnector2(RJ-45)
