12Harddiskdrivebay3
25CPU2DIMMs(varybymodel)
13Harddiskdrivebay2
Notes:
•Thelow-profilePCIcardbracket20andmainPCIcardbracket21areavailableinservermodelsthat
comewithaRAIDcard.
•Ifyourserverhasuptofour3.5-inchhot-swapSATAorSASharddiskdrives,thehot-swapSATAorSAS
harddiskdrivesneedtobeinstalledintotheharddiskdrivebays0,1,2,and3.
Thefollowingillustrationshowsthecomponentsofservermodelswithuptosixteen2.5-inchhot-swap
SASharddiskdrives.
Figure13.Componentsofservermodelswithuptosixteen2.5-inchhot-swapSASharddiskdrives
1Heatsinkandfanassembly2
18Harddiskdrivebay5
2CPU1DIMMs(varybymodel)
19Harddiskdrivebay4
3Heatsinkandfanassembly1
20Harddiskdrivebay3
4IntelligentDiagnosticsModule(availableinsome
models)
21Harddiskdrivebay2
5Frontpanel22Harddiskdrivebay1
6Opticaldrivebay2(withanopticaldriveinstalled
insomemodels)
23Harddiskdrivebay0
7Opticaldrivebay1(withanopticaldriveinstalled)
24Frontsystemfan1
30ThinkServerTD340UserGuideandHardwareMaintenanceManual
