1Heatsinkandfanassembly2
11Harddiskdrivebay0
2CPU1DIMMs(varybymodel)
12Frontsystemfan1
3Heatsinkandfanassembly113Frontsystemfan2
4IntelligentDiagnosticsModule(availableinsome
models)
14Systemboard
5Frontpanel
15Systemboardbattery
6Opticaldrivebay2(withanopticaldriveinstalled
insomemodels)
16Expansioncard(variesbymodel)
7Opticaldrivebay1(withanopticaldriveinstalled)
17Rearsystemfan3
8Harddiskdrivebay318Powersupply
9Harddiskdrivebay2
19CPU2DIMMs(varybymodel)
10Harddiskdrivebay1
CRUidentification
CRUsarepartsthatcanbeupgradedorreplacedbythecustomer.IfaCRUisdeterminedtobedefective
duringthewarrantyperiod,areplacementCRUwillbeprovidedtothecustomer.Customersareresponsible
forinstallingtheself-serviceCRUsforthisproduct.Customersalsocaninstalloptional-serviceCRUs,which
mightrequiresometechnicalskillsortools,orrequestthatatechnicianinstalltheoptional-serviceCRU
underthetermsoftheapplicablewarrantyservicetypeforyourcountryorregion.
Non-CRUsmustbereplacedonlybytrainedservicetechnicians.
ThefollowingtableliststhemajorFRUsinyourserverandtheCRUidentificationinformation.Foracomplete
listingofFRUinformation,suchasFRUpartnumbersandsupportedservermodels,goto:
http:/www.lenovo.com/serviceparts-lookup
Notes:
•BeforeservicingaLenovoproduct,ensurethatyoureadandunderstand“Safetyinformation”onpageiii
.
•UseonlypartsprovidedbyLenovo.
Description
Self-serviceCRUOptional-service
CRU
Frontsystemfan
YesNo
FrontpanelboardassemblyNoYes
HarddiskdriveYesNo
Heatsinkandfanassembly
YesNo
Hot-swaphard-disk-drivebackplane(availableinsomemodels)
NoYes
Hot-swapredundantpowersupply(availableinsomemodels)
YesNo
Intelligentdiagnosticmodule(availableinsomemodels)
NoYes
KeyboardYesNo
MemorymoduleYesNo
MicroprocessorNoYes
MouseYesNo
Non-hot-swappowersupplyassembly(availableinsomemodels)
NoYes
Opticaldrive
YesNo
