Page 53
MegaRAID SAS Software User Guide Chapter 4: WebBIOS Configuration Utility
| Overview
Chapter 4
4.1 Overview The WebBIOS CU, unlike the MegaRAID Storage Manager™ software, resides in the SAS
controller BIOS and operates independently of the operating system.
You can use the WebBIOS CU to do the following tasks:
Create drive groups and virtual drives for storage configurations
Display controller, drive, virtual drive, and battery backup unit (BBU) properties, and
change parameters
Delete virtual drives
Migrate a storage configuration to a different RAID level
Detect configuration mismatches
Import a foreign configuration
Scan devices connected to the controller
Initialize virtual drives
Check configurations for data consistency
Create a CacheCade configuration
The WebBIOS CU provides a configuration wizard to guide you through the
configuration of virtual drives and drive groups.
4.2 Starting the WebBIOS CU Follow these steps to start the WebBIOS CU and access the main screen.
1. When the host computer is booting, hold down the <Ctrl> key and press the <H>
key when the following text appears on the screen:
Press <Ctrl><H> for WebBIOS
The Controller Selection screen appears.
2. If the system has multiple SAS controllers, select a controller.
3. Click Start to continue.
The main WebBIOS CU screen appears.
NOTE: On systems that do not have the PS2 port, you must enable 'port 60/64
emulation' in the System BIOS to emulate USB as PS2. When this option is disabled on
this system, WebBIOS does not work.
WebBIOS Configuration Utility
This chapter describes the WebBIOS Configuration Utility (CU), which enables you to
create and manage RAID configurations on SAS controllers.
